Original price was: ₨ 506.₨ 469Current price is: ₨ 469.
| Range | Easy9 |
|---|---|
| Application | Protection |
| Type of product or equipment | Miniature circuit breaker |
| Poles | 2P |
| Number of protected poles | 2 |
| In assigned employment current | 16 A |
| Network type | THAT |
| Trigger type | Thermal-magnetic |
| Trigger curve | C |
| Cutting power | 4500 A Icn at 400 V AC 50 Hz conforming to IEC 60898-1 4500 A Icn at 230 V AC 50 Hz conforming to IEC 60898-1 |
| Sectioning Ability | CA compliant with IEC 60898-1 |
| Network frequency | 2 phases |
|---|---|
| [Ue] assigned operating voltage | 400 V AC 50 Hz |
| Magnetic trigger | 5,,,10 x In |
| [Uimp] assigned impulse withstand voltage | 4 kV |
| Fully visible cut | Regulated switching mode |
| Order type | By crankpin |
| Voltage indication | Without |
| Installation mode | Snap-on |
| Mounting bracket | Direct mounting on locking rods |
| 9mm pitch | 4 |
| Height | 82 mm |
| Width | 36 mm |
| Depth | 74 mm |
| Mechanical life | 10000 cycles |
| Electrical life | 4000 cycles |
| Connection | Cage type terminal (top or bottom) 1…25 mm² rigid Cage type terminal (top or bottom) 1…16 mm² flexible |
| Tightening torque | 2 Nm top or bottom |
| Differential protection | Without |
| Standards | IEC 60898-1 |
|---|---|
| IP protection degree | IP20 IP40 (modular housing) |
| Tropicalization | 2 comply with IEC 60364-8-1 |
| Relative humidity | 95% at 55°C |
| Ambient operating temperature | -25…60 °C |
| Ambient storage temperature | -40…85 °C |
| Packaging type 1 | PCE |
|---|---|
| Number of products in packaging 1 | 1 |
| Package height 1 | 3,500 cm |
| Package width 1 | 7,500 cm |
| Package length 1 | 8,500 cm |
| Package weight 1 | 210,000 g |
| Packaging type 2 | BB1 |
| Number of products in packaging 2 | 6 |
| Packaging height 2 | 8,000 cm |
| Package width 2 | 8,500 cm |
| Package length 2 | 22,000 cm |
| Package weight 2 | 1,301 kg |
| Packaging type 3 | S03 |
| Number of products in packaging 3 | 42 |
| Packaging height 3 | 30,000 cm |
| Package width 3 | 30,000 cm |
| Package length 3 | 40,000 cm |
| Package weight 3 | 9,535 kg |
