Legrand Surge protector with integrated short-circuit protection type T2 Imax 40kA – 1P+N 320V~ – 4 modules (412214)

Description

Product Characteristics

• Connection diagram :No
• IT connection diagram: No
• TN connection diagram: Yes
• NC connection diagram: Yes
• TN-CS connection diagram: Yes
• TN-S connection diagram: Yes
• TT connection diagram: Yes
• Other connection diagram: No
• Number of conductors (without grounding): 2
• Nominal discharge current In (8/20): 20kA
• Max. discharge shock current (8/20): 20kA
• Nominal AC voltage: 230V
• Maximum steady-state voltage: 320V
• Level of protection: 2.5kV
• Protection level LN: 2.4kV
• N-PE protection level: 1.5kV
• Built-in auxiliary fuse: Yes
• Installation method: 35 mm hat profile
• Size (DIN): 4 TE
• Max. rigid conductor cross-section (single-wire/multi-wire): 35mm²
• Max. flexible conductor cross-section (fine wire):25mm²
• With remote signaling contact: Yes
• Device level signaling: Optical
• Test class type 2: Yes
• Protection class (IP): IP20
• Width: 71.2mm
• Height: 96.5mm
• Depth: 77.5mm
• Impact resistance (IK): IK04
• Operating/installation temperature: -25-70°C
• Storage temperature: -40-70°C
• Nominal voltage (Un): 230-240V
• Frequency: 50-60Hz
• Direction of power supply: From above
• Indication of the location of the connection terminals: Yes
• Color: Gray
• RAL number: 7035
• Halogen-free: Yes
• Connection type: Screw terminal
• Terminal capacity: 6-35mm²
• Connection type: Cable
• With text area/writing surface: Yes
• EAN/Gencode: 3414971552913
